Concrete Spun Pole Making Machine

Qingzhou Water Conservancy Machinery Factory Co., Ltd. (BaoLai Brand), is a factory and supplier that can offer Concrete Spun Pole Making Machines. Our commitment to excellence is evident in every product we offer, designed to deliver unmatched reliability and efficiency. At BaoLai Brand, we provide the tools you need to achieve success with machinery that exemplifies durability and precision in concrete pole production.

Model:Model LWC 80-4 Centrifugal Concrete Making Machine

Send Inquiry

Product Description

The BaoLai Brand Concrete Spun Pole Making Machine is designed to produce high-quality concrete poles with internal diameters from 200 to 1200 mm and lengths ranging from 2000 to 5000 mm. It accommodates various joint types, including Flat Joint, Socket & Spigot Joint, and Tongue & Groove Joint, and can create poles with or without steel reinforcement. Custom mold options are available to meet specific requirements. All products adhere to Chinese National standards, making them suitable for demanding applications like deep wells, city drainage, and highway culverts. The machine delivers a production rate of 3-4 units per hour, combining versatility with high efficiency.

Baolai Brand Concrete Spun Pole Making Machine Parameters：

BaoLai Brand Centrifugal Concrete Making Machine ModelLWC 60-4
Pipe Diameter (mm)	500-600
Pipe Length (mm)	4000
Interfaces available	Flat Joint / Socket & Spigot Joint / Tongue & Groove Joint
Motor Power（kw）	22kw(brand new)
Motor Model	YCT250-4B
Wheel Diameter（mm）	Φ500,Exclusive tech, no need to worry about theaxlebroken
Productivity（unit/h）	3-4
Workers Needed	5-6 workers might needed
